Netgate 7100 RAID 1 Installation Kit

  • $50000

Find A Partner

Complete Installation Kit for adding a RAID 1 Installation to an Netgate 7100 1U.

The Kit includes the following parts:

  • 2x 256GB 2.5" SATA SSD
  • 2x 2.5" Fixed HDD/SDD Bracket with mounting screws
  • 2x 10" SATA Gbps Cable with locking latch


256GB 2.5" SATA SSD

Storage upgrade option for RAID / Mirroring configurations in XG-1537 and XG-1541 systems

Technical Information


  Interface:   SATA III 6GB/s
  Capacity:   256GB
  Dimension:  100mm x 69.85mm x 7.00mm
  Weight:   43g
  Flash:   MLC
  MTBF:   2,000,000 Hours
  Operating Voltage:  +0.5V (±5%)
  Power Consumption:   0.25W (Idle)
 .94W (Active)
  Operating Temperature:   0 to 70°C
  Max transfer performance:   563 MB/s
  Max transfer performance:             452 MB/s



WARRANTY AND SUPPORT INFORMATION:

No returns

1 year manufacturers limited warranty

All Specifications subject to change without notice.
